YIHUA 853AA/853AAA digital SMD soldering desoldering hot air gun preheat BGA rework soldering station

No.853AA/853AAA

This rework station features a PID programmable temperature control system and real-time temperature tracking for each component, as well as an automatic temperature correction with a rapid compensation speed and minimum tolerance. MOQ : ＞50pcs Qty: 4PCS/CTN

SPECIFICATION

The hot air gun utilizes a ceramic skeleton heater to provide a rapid but uniform hot air. It uses an upgraded version of previous fan models for a larger airflow rate, and generates a strong spiral wind with a longer service life.
The 853AAA soldering iron uses an imported heater with a rapid heating speed, reliable performance and longer lifespan. The anti-static design prevents delicate SMD components from damage caused by static or electricity leakage.
The self-detection system has an intelligent malfunction display and alarm function in the event of overheating, short circuits, open circuits, overload, and other potentially harmful conditions.
The personalized pre-heating platform is covered with a thermal insulation pad for added safety. It features magnetic induction technology, meaning the loaded circuit boards or electronic components will be attached to the platform using 360 degree rotary stoppers for future processing.
Temperature Correction Function: The rework station will automatically correct the temperature due to environmental changes or replacement of the heating coil, solder iron or other components with a temperature correction range of -50℃ ~+50℃.
The temperature display mode changes between Celsius and Fahrenheit according to different markets.
The hot hair gun features both manual and automatic functions according to specific customer uses. We recommend using manual mode if you are continuously using the air gun, thus saving heating time for a higher efficiency.
Hot Air Gun Protection Function: The heater will stop heating if any abnormal conditions occur, guaranteeing a higher safety performance.

Model	853AA	853AAA
Rated voltage	220-240V/AC 50HZ
Rated power	1150W	1200W
Control unit dimensions	L320W220/H100mm±5MM
Operating ambient temperature	0-40℃/32-104℉
Preheat station
Temperature range	50-400℃/122-752℉
Display	LED
Heating suface area	120*120mm
Hot air rework station
Air delivery	Brushless blower with smooth air delivery
Air volume	≤120L/MIN
Temperature range	100-480℃/212-896℉
Display	LED
Soldering station
Temperature range	NO	200-480℃/392-896℉
Display	NO	LED
Tip to ground resistance	NO	＜2Ohms

Application
This equipment is suitable fora various kind of soldering or de-soldering (removals) purposes of the electronic components such as: SOIC, CHIP, QFP, PLCC, BGA, SMD, etc. It is ideal for other purposes, including thermo shrinking, paint drying, adhesive removal, thawing, warming, plastic welding, etc. It is especially ideal for mobile phone's cable.
